Micro Switch, KW Series
Main Specification:
Operating speed | 0.1mm~1m/s (no lever) | |
Operating frequency | Mechanical 60 cycles/min; Electrical 250 cycles/min | |
Insulation resistance | ≤100MΩ(500VDC) | |
Contact resistance | Terminal type≤mΩ; Wire type≤100mΩ | |
Test Voltage | Between terminals of the same polarity | AC1000V, 50/60Hz, 1min |
Between current carrying metal parts and ground(case), and between each terminal and non-current carrying metal parts. | AC1500V, 50/60Hz, 1min | |
Vibration resistance | 10~50Hz, 1.5mm double amplitude | |
Shock resistance | Endurance: 1000m/s² (approx.100G)max Wrong action: 300m/s²(approx.100G)max | |
Electric shock proof protection grade | II class | |
Degree protection by enclosure | IEC IP65(Besieds terminal part of terminal type) | |
Life expectancy | Mechanical≥2000000 cycles Electrical≥50000 cycles |
