0.75" Multi-Gauge Permanent Piezo Middle Pressure Tool

The ENGELEC downhole Multi-Gauge Piezo Bottom Pressure Tool can be used on its own or at the bottom of a multi-gauge pressure system. Our Multi-Gauge Piezo Bottom Pressure Tool is easy to install and produces high quality reservoir data in real time. It’s fully welded construction, dual protection metal to metal seal design, and hermetically sealed electronics make it a very reliable product. This is the final gauge in a multi-gauge system. Alternatively, this gauge can be used on it’s own as a single gauge in a single gauge system.
  • PPMPT
  • ENGELEC
  • PPMPT
  • 0.75"
Gauge:

Permanent Downhole 0.75" Multi-gauge Passthrough Piezo Tool - Middle Gauge

ApplicationENGELEC_Permanent downhole_Gauges_Multi Gauge PassThru Piezo Measurements

ENGELEC Multi-Gauge Passthru Piezo Tool is used for multi gauge applications. It has the capability to connect up to 8 gauges on a single conductor. The passthru gauge acts as a pressure gauge and eliminates the need for a WYE splice, reducing the number of connections needed; making it a more cost effective and reliable option.

Features
  • 8 Gauges on a Single Conductor

  • No WYE Needed

  • Slim 0.75" Diameter

  • Cablehead Top

  • Cablehead Bottom

  • Fully Welded Construction

  • Hermetically Sealed

  • Dual Protection Metal to Metal Seal Design

  • Corrosion Resistant - NACE MR0175

    Benefits

    The Multi-Gauge Passthru Piezo Tool is quick and easy to install and produces high quality well or reservoir data in real time. Its fully welded construction, dual protection metal to metal seal design, and hermetically sealed electronics, make it a very reliable gauge. Since it acts as both a gauge and a WYE splice, it helps reduce the cost of the permanent system while increasing reliability.

    Quick Specs

    Name OD Maximum Temperature Maximum Pressure
    Permanent downhole Pass through Piezo Multi-gauge Middle  0.75" 150°C 15,000 psi
