U Type Terminal Blocks
General
♦ Plastic shell: ERPP hot plasticity UL 94v-2 flame retardant,grade,excellent insulation Not easy to aging
♦ Spring: high-grade steel, tenacity
♦ Product features:a total of five models,special color can be custom, applicable to contain 22 -10(AWG) combination of all kinds of wire diameter of wire
♦ Application: suitable for all kinds of electrical products,household wiring terminal equipment,such as reusable, safe and reliable
ITEM.NO. | (H) | (w) | (D) | SUITABLE WIRES | COLOR |
(mm) | (mm) | (mm) | |||
P71 | 15 | 8.5 | 6.5 | MIN#20X1+#22X1 | Grey |
MAX#16X2 | |||||
P72 | 18 | 10 | 7.5 | MIN#20X3 | Blue |
MAX#16X3 | |||||
P73 | 20 | 11.5 | 9.5 | MIN#20X3 | 0range |
MAX#16X3+#18X1 | |||||
P74 | 23.5 | 13.5 | 10.8 | MIN#14X1+#18X1 | Yellow |
MAX#14X4+#18X1 | |||||
P75 | 23.5 | 15.5 | 12.7 | MIN#14X2 | Red |
MAX#10X2+#12X2 |
